12 CHANNEL NTC INPUT DATALOGGER SZ-40010

12 CHANNEL NTC INPUT DATALOGGER SZ-40010

  • Voltage Monitoring.

  • Phase Sequence Monitoring.

  • Phase Loss and Phase Unbalance detection.

  • UV and OV Detection.

  • Settable UV and OV Parameter.

12 CHANNEL NTC INPUT DATALOGGER SZ-40010

Display 7" TFT LCD, full view
Resolution (WXH) 800 X 480
Colors 24-bit Colors
Brightness 360cd/m2
Backlight LED
Backlight Life 50000 hours
Touch Panel 4 wires resistive touch screen (Surface Hardness 4H)
CPU 600 MHz ARM Cortex-A8
Memory 128MB Flash + 128MB DDR3
RTC Built In
Ethernet NA
SD Card NA
USB Port 1USB Host 2.0, 1 USB Device 2.0
COM Port COM1: RS232/RS485/RS422
COM3: RS232
Power Consumption < 10W
Input Power DC 24V, Input Range: DC 9V - 12V
Power Protection Protected from thunderstrike and surging
Power Down Allowed < 5mS
Operating Temperature -40.0 to 90.0°C
Storage Temperature -30 to 80°C
Operating Humidity 10-90% RH (No Condensation)
Vibration Endurance 10-25Hz (X/Y/Z 2G/30Min)
Cooling Natural air cooling
Degree of Protection Front IP54, Back IP20
Shell Material ABS
Panel Cutout (WXH) Wall Mount
Dimension 250mm X 300mm X 110mm
Weight About 1100g
Datalogging YES
Printer Connectivity YES
Sensor Type NTC(12 Nos)
Relay Output 5A, 250 VAC (2 Nos)
BMS Connectivity YES

12 CHANNEL NTC INPUT DATALOGGER SZ-40010
