8 CHANNEL PT100 INPUT DATALOGGER SZ-40001

8 CHANNEL PT100 INPUT DATALOGGER SZ-40001

  • Voltage Monitoring.

  • Phase Sequence Monitoring.

  • No welding of adopter required.

  • Forged/brazed as per model thereby eliminating leakages.

8 CHANNEL PT100 INPUT DATALOGGER SZ-40001

Display 4.3" TFT LCD
Resolution (WXH) 480 X 272
Colors 24-bit Colors
Brightness 450 cd/m2
Backlight LED
Backlight Life 50000 hours
Touch Panel 4 wires resistive touch screen (Surface Hardness 4H)
CPU 600 MHz ARM Cortex-A8
Memory 128MB Flash + 128MB DDR3
RTC Built In
Ethernet NA
SD Card NA
USB Port 1USB Host 2.0, 1 USB Device 2.0
COM Port COM1: RS232/RS485/RS422
COM2/COM4: RS485
Power Consumption < 6W
Input Power DC 12V, Input Range: DC 9V - 12V
Power Protection Protected from thunderstrike and surging
Power Down Allowed < 5mS
Operating Temperature "-50.0 to 400.0°C"
Storage Temperature "-20 to 70°C"
Operating Humidity 10-90% RH (No Condensation)
Vibration Endurance 10-25Hz (X/Y/Z 2G/30Min)
Cooling Natural air cooling
Degree of Protection Front IP54, Back IP20
Shell Material ABS
Panel Cutout (WXH) 147mm X 147mm
Dimension 160mm X 160mm
Weight
Datalogging YES
Printer Connectivity YES
Sensor Type PT-100 (8 Nos)
Relay Output 5A, 250 VAC (2 Nos)
BMS Connectivity NA
